Mach V1 Ultra
4-Axis All in One Cinema Camera
With DJI Ronin 4D, our most advanced technologies have been integrated into one cutting-edge and comprehensive cinematography solution, which offers groundbreaking flexibility to solo cinematographers and unlimted possibilities for coordinated shooting.
It offers a completely unique design. Crafted with carbon fiber and aluminum magnesium, its solid body integrates the imaging, stabilization, and focusing systems, as well as wireless transmission and control. This avoids time-consuming setup and enables quicker shooting.
Client
Mach Innovatons
Year
2021 - 2022
Designer
Jaewan Jeong
Simon Kim
Ang Chao
My Contribution
Project lead
Concept development
Industrial design
User experience
Color, material and finish
Design for manufacture
Introducing Ronin 4D
Integrated and Modular: Both Realized in One Camera
Final model designed by the DJI Design team
Everything starts from insight
I went to United States with my working prototypes to have interviews with great directors like Gareth Edwards, Star Wars Director and Claudio Miranda, Winner of Oscars Award.
1st Prototype
2nd Prototype
3rd Prototype
4th Prototype
Final Prototype
I spend about 2 years making several prototypes and collects all feedback from professionals, and made prototypes over and over again.
After 5-6 rounds of making samples, eventually I organized and defined the current key components layout and usability of cinematography shoothing.
